2.4GHZ Frequency Counter-AEI-90

Product Description

AEI-90 is a  Frequency Counter is used for measuring the frequency. It usually measures the frequency by measuring the number of pulses or oscillations per second in repetitive electronic signal. It is a microprocessor based counter that measures frequency, pulse and crystal measurements. It is a high resolution multi-functional counter with 5-range function select, 8-digit LED display and 4-step gate time. Our frequency counter finds application in Indian defense academy, telecommunication industry, military, aerospace and many more.

• It is a high-resolution multifunction intelligent frequency counter based on microprocessor.
• Frequency measurement, pulse counting, crystal measurement.
• 4-step gate time, 5-range function select and 8-digit LED display.
• Working mode memorized, range and gate time can be set according to the requirement.
• Multifunctional, good quality and reasonable price.

Technical Specification:-

• Frequency measurement : CH A: 5OMHz~2.4GHz, Basic
• CH B: 10Hz~5OMHz, Basic Accuracy
• Crystal measurement : Crystal Slot : 3.5MHz~16MHz, Basic Accuracy
• Total measurement : CH B: 10Hz~4MHz, Basic Accuracy
• Measurement sensitivity : 50mVrms
