Mortuary Chamber

Product Description

Mortuary Chamber  is Double-walled with mild steel/prefabricated panels for outer surface and stainless steel inner chamber with insulation in between. Front opening, hinged insulated doors lined with magnetic gasket,handle and lock arrangements with keys in duplicate for individual dead bodies.

Trays to carry dead bodies with handles at both ends travel on rollers fitted for easy movements. Exterior surface in chemically treated, ant rust coated and duly finished with powder coated paint. To avoid any moving part inside the cabinet, for easier maintenance/ and cleaning refrigeration unit is kept outside the chamber and fixed at rear, temperature of -2.c to 5.c is maintained by hermetically sealed refrigerator compressor unit and is controlled by an automatic electronic solid state digital temperature controller cum indicator temperature controller is mounted on front panel. Provided on front top, along with pilot lamp main switch etc. supplied complete with trays, cord and plug.Suitable to work on 220 V. Single phase 50 Hz ac supply.



Mortuary Chamber is Used to storing cadaverous under low temperature cool condition in order to prevent decomposition. These units are double walled with outer made of M.S. sheet duly painted and inner wall of stainless steel. Front opening covered door with magnetic gasket lock & key and handle individual chambers are provided independent lock with duplicate keys. Trays made of G.l. sheet to carry dead bodies are provided with handles.Trays travel on rollers fitted with ball bearing for easy movement.Hermetically sealed compressor serves refrigeration unit, to maintain temperature range of 2^oC to 5^oC or (-) 15^oC to (-) 20^oC (as ordered) Unit is fitted with Digital Temperature Indicator-cum-controller. Works on 220/230 volts A.C. Power supply.

Mortuary Chamber  Capacity Temp. Temp. Voltage Stabilizer

a) Single Body 2^o to 5^oC -15^o to -20^oC 3KVA
b) Two Bodies 2^o to 5^oC -15^o to -20^oC 4 KVA
c) Three Bodies 2^o to 5^oC -15^o to -20^oC 5 KVA
d) Four Bodies 2^o to 5^oC -15^o to -20^oC 8 KVA
e) Six Bodies 2^o to 5^oC -15^o to -20^oC 8 KVA

State-of-the-Art Temperature and Sterilization Control

Maintain optimum preservation conditions with a fully digital microprocessor-based control system and digital temperature indicators. The chamber operates at 2C-8C, supported by hermetically sealed compressors and an automatic defrost function. Spraying sterilization, steam jacketed design, and programmable sterilizing cycles (1560 minutes) guarantee hygienic conditions with automatic operation.


Safe, Durable Construction for Ultimate Protection

Constructed from premium Stainless Steel 304 for inner chambers and powder coated GI/SS 304 exteriors, the unit retains structural integrity and resists corrosion. Advanced safety features include audio-visual alarms, silicon rubber magnetic gaskets for leak sealing, and a heavy-duty hinged door with secure lockingensuring both contents and users are protected.


Mobility and User-Friendly Features

Designed for convenience, this mortuary chamber is fitted with heavy-duty castor wheels for effortless movement. Both outer and removable inner trolleys are provided to simplify handling. All operational parameterstemperature, sterilization, and timingare digitally monitored for accuracy, while automatic spraying and insulated walls further improve performance and ease-of-use.
